    Trumpeter 1/35 01023 MPQ-53 C-Band Tracking Badar

    Trumpeter 1/35 01023 MPQ-53 C-Band Tracking Badar

    Pre-subscribe now at page bottom & save 8%, Limited Time!
    $52.99USD
    $66.00USD $52.99USD
    Sale Sold out
    Shipping calculated at checkout.

    8 in stock

    ⏱ Processing: 1–3 days  |  🚚 Usual Delivery: 7–14 days (US、UK)

    Details of TRUMPETER 01023 1/35 Scale AN/MPQ-53 C-Band Tracking Radar Plastic Model Kit

    Basic Specs

    • Brand：Trumpeter
    • Item No.：01023
    • Scale：1/35
    • Name：US AN/MPQ-53 C-Band Multifunction Phased Array Tracking Radar for MIM-104 Patriot Air Defence System
    • Material：Plastic and one sheet photo-etched brass parts
    • Assembly Type：Glue required plastic model kit
    • Finished Dimensions：Length approx 294.5mm, Width approx 172.5mm
    • Total Parts：Over 410 parts
    • Paint & glue：Not included

    Kit Contents

    • Plastic sprues for radar shelter, phased array antenna, M860 trailer chassis and support outriggers
    • Hollow rubber tires with realistic heavy-duty tread pattern
    • Transparent parts for instrument panels and cabin viewing windows
    • Detailed internal cabin equipment and control panel structures
    • One sheet of photo-etched brass for antenna mesh, grilles, latches and fine exterior fittings
    • Deployable support jack assemblies
    • Cable brackets and external stowage accessories
    • Decal sheet for multiple US Army air defence unit marking options
    • Assembly and painting instruction manual

    Product Features

    • 1/35 scale kit representing US AN/MPQ-53 C-band phased array tracking radar of MIM-104 Patriot air defence missile system
    • Fine engraved panel lines and realistic shelter texture on radar cabin and trailer body
    • Highly simulated large phased array antenna panel with accurate surface details
    • Radar antenna can be built in travelling folded position or erected deployed combat position
    • Functional foldable outrigger jacks to stabilise the trailer for field deployment display
    • Detailed multi-directional slide-molded radar shelter cabin with interior equipment details
    • Hollow rubber tires with authentic heavy trailer tread pattern
    • Photo-etched parts enrich delicate antenna mesh, cable brackets and small exterior fittings
    • Authentic US Army camouflage and air defence unit marking schemes
    • Fully reproduced trailer connection structure for pairing with HEMTT tractor

    Historical Background

    • The AN/MPQ-53 is the core multifunction C-band phased array radar of the MIM-104 Patriot PAC-2 air defence missile system.
    • It integrates target search, detection, tracking, identification and missile guidance functions in a single unit.
    • Capable of tracking more than 100 targets simultaneously and guiding up to 9 Patriot missiles to intercept threats.
    • Mounted on M860 heavy semi-trailer and towed by HEMTT tractor for rapid battlefield relocation and deployment.
    • Entered US Army service in the 1980s and became famous for ballistic missile interception during the Gulf War.
    • This radar unit works together with launching stations and engagement control station to form a complete mobile air defence battery.
